Introduction
ARC-10 is a top quality, easy to use GSM controller for alerting and remote control using SMS. The rail mount unit incorporates a Quad Band (850/900/1800/1900MHz) GSM/GPRS modem, two digital inputs, two power relay outputs and a serial RS-232 port. Up to five hundred users can be configured to switch a relay output via a toll-free phone call (e.g. for opening the garage door or a parking barrier). Ten users can be configured as alert recipients.
All SMS functionality remains intact during GPRS operation. This means one can use the unit as a wireless modem to communicate with a remote serial device e.g. a traffic light controller or a vending machine and simultaneously benefit from the SMS alerting and remote control functionality.
Features
- 2 digital inputs.
- 2 power relay outputs.
- One output can be configured to switch with a toll-free phone call.
- Simple SMS commands for both configuration & control.
- SMS commands can be passed through the local serial port for testing and commissioning.
- Flexible user administration.
Simple setup and operation
All setup and control can be done using a mobile phone. Simple ASCII configuration commands are used for unit setup and control. Several commands can be packed in one SMS. The RS-232 interface can be used to alternatively setup and test the unit using a PC or an ASCII terminal.The rich command set features commands for configuring input alarm parameters, defining users and controlling system outputs with time related parameters.
Applications
- Garage door opener
- GSM Access Control, more »
- Vending machines
- Security systems
- Fire and smoke alarming
- Lights control
- Home automation
- Heating control
- Greenhouse controls
- M2M systems
Ordering Codes
| Code | Description |
|---|---|
| ARC-10 | Alarming and Remote Control Unit |
Specifications
| Power supply | |
|---|---|
| Supply voltage | 12…24 VDC ±10{edbfe352f301579bb332dff86ced542172b0c80ed0c941f0c02cdd1fe307a783} |
| Supply current | average 30mA to 120mA max (all DO on), 2A peak |
| Inputs/Outputs | |
| Digital inputs | 2, 12..30VDC |
| Digital outputs | 2, relay 250V/8A (AC1) |
| Communication | |
| Wireless modem | Quad Band GSM/GPRS (850/900/1800/1900MHz) |
| RF connector | SMA Jack |
| Serial interface | RS232C, up to 921 kBit/s |
| Other | |
| Temperature | -10°C…+55°C, operating |
| Indications | LED, network status |
| Dimensions | 71 x 90 x 58 mm |
| Weight | 0.2 kg |
| Mounting | DIN rail |
| Command set | Simple ASCII SMS commands for system configuration, alarm settings and remote control |
