Adeunis LoRaWAN fieldtester

0.00 kr

DESCRIPTION

Field Test Device – Network validation, prior to your solution deployment.

The LoRaWAN Field Test Device by ADEUNIS is a ready-to-use system which provides connection to any operated network using the LoRaWAN protocol. It allows to transmit, receive and instantly view the radio frames on the used network. Equipped with a large LCD screen, you can check all operating information (GPS coordinates, temperature, battery …) and use of the network (uplink, downlink, sensitivity, Packet Error Rate …). Its ultra-fast and precise GPS optimises geolocation operations. This Field Test Device is particularly suitable for the validation of applications like sensor networks, asset tracking, smart buildings, metering, security or M2M. With built-in rechargeable battery, this demonstrator allows for many hours of use and can be recharged with any type of mobile phone charger.

  • LoRaWAN – EU/NZ/AUS compliant (available in EU868, AS923 & AU915)
  • LoRaWAN network validation
ADDITIONAL INFORMATION
Sensor Type
LoRaWAN EU868 AU915 AS923
Temperature
GPS – Geolocation

MAIN FEATURES

  • Immediate visualization of network coverage data
  • Geolocation of measurement points
  • Dedicated web application
  • Configuration via mini USB
  • Complete integration into LORAnexus and LORA ready
SPECIFICATIONS
Display Ul/DL – Channels – RSSI/SNR/PER/GPS/Temperature
 Dimensions LxWxH 180x72x21mm
 Operating Temperature  -20 … +75 °C
 Weight 250g
 Power Supply  Internal 3.6V Lithium rechargeable Battery
 Radiated RF Power  14 dBm
 RF-Input sensitivity  -126 dBm
Kategorier: , Etikett:

Beskrivning

Brand: Adeunis
Product Code: ARF8124C

Availability: In Stock
Weight: 250.00g
Dimensions: 180.00mm x 72.00mm x 21.00mm
